 Posted - Mar 05 2014 : 09:13:44
|
Hi,
We're using ImageEN components throughout our Delphi software and recently updated from 5.0.5 to 5.0.6. Now we're getting reports from users about Access Violations and Out Of Memory errors. It turns out that suddenly some images are not handled correctly.
We use this code to add an image to an image list runtime:
theImageIO := TImageEnIO.Create(nil);
theBMP := TIEBitmap.Create;
theBMP.Location := ieMemory;
theImageIO.LoadFromFile(mImagePath);
theBMP.Assign (theImageIO.IEBitmap);
if mImageIndex < 0 then
mImageIndex := dmGlobal.ilSmall.AddMasked(theBMP.VclBitmap, TColor($FF00FF))
else
dmGlobal.ilSmall.ReplaceMasked(mImageIndex, theBMP.VclBitmap, TColor($FF00FF));
ilSmall is a normal TImageList. I've attached an image (FYI: it is a picture of actress Abigail Breslin) sent to us by a user. The image causes many crashes. The weird thing is, it doesn't always crash in the same code. Sometimes it is in the JPEG image reader code, sometimes in standard Delphi functions in units like GETMEM.inc and system.pas. Or it just hangs or throws a Out Of Memory error.
However when it crashes, it is related to the image. Once we downgraded to 5.0.5 again, the crashes are gone. I hope this helps.
King regards,
Ronald Kats
Collectorz.com
 |
|
|
w2m
USA
1990 Posts |
Posted - Mar 05 2014 : 10:00:59
|
I have never seen imageen produce the problems you describe, so it is unlikely the problem is caused by imageen itself... rather there are problems with your code.
Without seeing all your code it is difficult to know the real problem, but I noticed you create a TIEBitmap, but do not set the TheImageEnIO.AttachedIEBitmap property:
theImageIO := TImageEnIO.Create(nil);
theBMP := TIEBitmap.Create;
theBMP.Location := ieMemory;
TheImageEnIO.AttachedIEBitmap := theBMP;
if mImageIndex < 0 then
mImageIndex := dmGlobal.ilSmall.AddMasked(theBMP.VclBitmap, TColor($FF00FF))
else
dmGlobal.ilSmall.ReplaceMasked(mImageIndex, theBMP.VclBitmap, TColor($FF00FF));
I am not sure if this will solve your problem, but you are assigning the bitmap incorrectly.
Also, when adding a image to an imagelist I generally use a TBitmap, not a TIEBitmap:
var
iBitmap: TBitmap;
dmGlobal.ilSmall.AddMasked(iBitmap, clBlack);
In addition, if the image dimensions do not match the settings in the imagelist there will be further problems, so it is good to resample the bitmap to make sure it is the correct size if necessary:
iBitmap := TBitmap.Create;
try
iImageEnIO := TImageEnIO.Create(nil);
try
iImageEnProc := TImageEnProc.Create(nil);
try
iImageEnIO.AttachedBitmap := iBitmap;
iImageEnIO.LoadFromFile(iImageName);
{ Add a TBitmap to the imagelist }
iImageEnProc.AttachedBitmap := iBitmap;
if (iBitmap.Width <> 16) and (iBitmap.Height <> 16) then
iImageEnProc.Resample(16, 16);
dmGlobal.ilSmall.AddMasked(iBitmap, clBlack);
finally
iImageEnProc.Free;
end;
finally
iImageEnIO.Free;
end;
finally
iBitmap.Free;
end;
This or similar code is used in several active applications to deal with imagelist's and there has been no problems.
I can load your sample image into ImageEnView with no errors with 5.0.6 here.
William Miller
Adirondack Software & Graphics
Email: w2m@frontiernet.net
EBook: http://www.imageen.com/ebook/
Apprehend: http://www.frontiernet.net/~w2m/index.html
Custom ImageEn Development |
 |
|
|
RonaldKats
Netherlands
5 Posts |
Posted - Mar 05 2014 : 11:28:21
|
Thanks for the quick reply. This code is only used for 16x16 images. The images already have been resampled and it includes a check for dimensions before this code is used.
I used the following code for the attached image to display in an TImageEnView. This fails in 5.0.6:
ImageEnView1.IO.LoadFromFileFormat(thePicturePath, FindFileFormat(thePicturePath,false) );
It is working fine in 5.0.5.
I've uploaded a zip with a demo project:
http://downloads.collectorz.com/AVImageView.zip
All it does is load the image. There are two builds in the zip, one with 5.0.5 and one with 5.0.6. Notice that the 5.0.5 build works, where the 5.0.6 one crashes. Copy the demopic.jpg from the zip file to your My Documents folder.
I hope this helps.
Kind regards,
Ronald Kats
Collectorz.com |
|
|
|
w2m
USA
1990 Posts |
Posted - Mar 05 2014 : 13:19:26
|
Unfortunately, your zip file was corrupt or you are using Delphi XE5. The project will not compile here at all...
I ran your two demos and both loaded the image, but 5.0.6 produced an exception then the image was shown. I am not sure if the problem is caused by ImageEn or by the code you are using to load the picture.
William Miller |
|
|
|
RonaldKats
Netherlands
5 Posts |
Posted - Mar 06 2014 : 01:51:04
|
Ah, yes, it is in XE5.
The code I use to load the picture, is entirely ImageEN's. Since it is just this one line:
ImageEnView1.IO.LoadFromFileFormat(thePicturePath, FindFileFormat(thePicturePath,false) );
If you open unit1.pas in a text editor, you'll see I'm not doing anything else. It is a simple demo, with only the ImageENView component where the image gets loaded in the FormShow. |
|
|
|
xequte
38611 Posts |
Posted - Mar 06 2014 : 14:10:16
|
Hi Ronald
I can reproduce the issue with the EXE you supplied, but not when I compile your demo myself in XE5.
Does the issue only occur with JPEG images?
Nigel
Xequte Software
www.xequte.com
nigel@xequte.com
|
|
|
|
RonaldKats
Netherlands
5 Posts |
Posted - Mar 07 2014 : 01:30:03
|
Hi,
Yes, so far it seems the reports are only about JPEG images indeed. One of the Access Violations I could reproduce was in the ImageEN JPEG reader. |
|
|
|
Murat
Russia
48 Posts |
Posted - Mar 12 2014 : 01:11:00
|
I experienced the same issue when tried to run the Ronald's code by XE5 and ImageEN 5.0.6.
All is Ok when I launch it using 5.0.1 version.
|
|
|
|
xequte
38611 Posts |
Posted - Mar 12 2014 : 16:15:44
|
Hi
We have a fix for this for v5.0.7, which will be released as soon as we finish implementation of a new feature (in the next week or two).
Email us if you are urgent for the fix.
Nigel
Xequte Software
www.xequte.com
nigel@xequte.com
|
|
|
|
Murat
Russia
48 Posts |
Posted - Mar 13 2014 : 01:37:16
|
| Did you have a chance to take look at the problem with PSD files that I sent you recently. I this issue was fixed I'd wanted to kindly ask you to send me the latest 5.0.7 version. Thanks! |
|
|
|
xequte
38611 Posts |
Posted - Mar 13 2014 : 17:23:37
|
Hi Murat
It is a corrupted file. For the next update we will make it cope with it more gracefully.
Nigel
Xequte Software
www.xequte.com
nigel@xequte.com
|
|
|
|
Murat
Russia
48 Posts |
Posted - Mar 14 2014 : 03:56:45
|
| Thanks! If you will include it into the 5.0.7 version, I'd be appreciate you'll send me the 5.0.7 version |
|
|
|
spurgeon
54 Posts |
Posted - Mar 17 2014 : 12:44:07
|
| We also just discovered a crash with an .MRW file and 5.0.6 (9.2MB so I can't attach to forum). Reverting to 5.0.5 fixed the problem for us. I assume this is also related to the same issue? Looking forward to the 5.0.7 update. |
|
|
|
xequte
38611 Posts |
Posted - Mar 17 2014 : 15:28:58
|
V5.0.7 should be ready within the week. If you post a link to you MRW file i can test it.
Nigel
Xequte Software
www.xequte.com
nigel@xequte.com
|
|
|
|
spurgeon
54 Posts |
Posted - Mar 18 2014 : 08:37:51
|
| Can't post a public link at the moment. I sent as an email attachment instead. Hope that's alright. |
|
|
|
Murat
Russia
48 Posts |
Posted - Mar 18 2014 : 09:06:44
|
| You can also share it via dropbox or wetransfer.com service. So only ImageEn developers will see your image. |
|
|
| |
