unit Unit1;

interface

uses
  Windows, Messages, SysUtils, Variants, Classes, Graphics, Controls, Forms,
  Dialogs, ExtDlgs, StdCtrls, ExtCtrls, imageenio, imageenproc, ieview,
  imageenview;

type
  TForm1 = class(TForm)
    Panel1: TPanel;
    Open1: TButton;
    Rotate1: TButton;
    ImageEnView1: TImageEnView;
    ImageEnProc1: TImageEnProc;
    ImageEnIO1: TImageEnIO;
    OpenPictureDialog1: TOpenPictureDialog;
    Save1: TButton;
    SavePictureDialog1: TSavePictureDialog;
    AddLayer1: TButton;
    Exit1: TButton;
    Merge1: TButton;
    procedure Open1Click(Sender: TObject);
    procedure Rotate1Click(Sender: TObject);
    procedure Save1Click(Sender: TObject);
    procedure FormCreate(Sender: TObject);
    procedure FormDestroy(Sender: TObject);
    procedure AddLayer1Click(Sender: TObject);
    procedure Exit1Click(Sender: TObject);
    procedure Merge1Click(Sender: TObject);
  private
    { Private declarations }
  public
    { Public declarations }
  end;

var
  Form1: TForm1;

implementation

{$R *.dfm}

uses hyiedefs, hyieutils, iexhelperfunctions;

procedure TForm1.AddLayer1Click(Sender: TObject);
var
  iLayer: integer;
  iWidth: integer;
  iHeight: integer;
begin
  iLayer := ImageEnView1.LayersAdd;
  { Set IO Params }
  ImageEnView1.IO.Params.BitsPerSample := 8;
  ImageEnView1.IO.Params.SamplesPerPixel := 4;
  iWidth := ImageEnView1.IEBitmap.Width;
  iHeight := ImageEnView1.IEBitmap.Height;
  { Render a transparent layer }
  ImageEnView1.IEBitmap.IEInitialize(iWidth, iHeight, clBlack, True);
  ImageEnView1.Update;
  ImageEnView1.LayersCurrent := iLayer;
  ImageEnView1.CurrentLayer.VisibleBox := True;
  ImageEnView1.CurrentLayer.Selectable := True;
  ImageEnView1.LayersDrawBox := True;
  ImageEnView1.CurrentLayer.Locked := False;
  ImageEnView1.MouseInteract := [miMoveLayers, miResizeLayers];
end;

procedure TForm1.Exit1Click(Sender: TObject);
begin
  Close;
end;

procedure TForm1.FormCreate(Sender: TObject);
begin
  IERegisterFormats;
  OpenPictureDialog1.Filter := GraphicFilter(TGraphic);
  SavePictureDialog1.Filter := GraphicFilter(TGraphic);
   { Set bitmaps to handle transparency }
  ImageEnView1.IO.Params.BMP_HandleTransparency := True;
  ImageEnView1.LayersResizeAspectRatio := iearALTKey;
  { Allow selection of transparent layers }
  ImageEnView1.SelectionOptions := ImageEnView1.SelectionOptions +
    [iesoSelectTranspLayers];
end;

procedure TForm1.FormDestroy(Sender: TObject);
begin
  IEUnregisterFormats;
end;

procedure TForm1.Merge1Click(Sender: TObject);
begin
  ImageEnView1.LayersMergeAll;
  ImageEnView1.Update;
end;

procedure TForm1.Open1Click(Sender: TObject);
begin
  if OpenPictureDialog1.Execute then
  begin
    ImageEnView1.IO.LoadFromFile(OpenPictureDialog1.Filename);
    ImageEnView1.Update;
  end;
end;

procedure TForm1.Rotate1Click(Sender: TObject);
begin
  ImageEnView1.IEBitmap.Rotate(45, True, ierBicubic, clWhite);
  ImageEnView1.LayersFixRotations(ImageEnView1.LayersCurrent);
  ImageEnView1.LayersFixSizes(ImageEnView1.LayersCurrent);
  ImageEnView1.LayersFixBorders(ImageEnView1.LayersCurrent);
  ImageEnView1.Update;
end;

procedure TForm1.Save1Click(Sender: TObject);
begin
  if SavePictureDialog1.Execute then
  begin
    ImageEnView1.IO.SaveToFile(SavePictureDialog1.Filename);
  end;
end;

end.
end.

object Form1: TForm1
  Left = 0
  Top = 0
  Caption = 'Rotate Layers'
  ClientHeight = 299
  ClientWidth = 635
  Color = clBtnFace
  Font.Charset = DEFAULT_CHARSET
  Font.Color = clWindowText
  Font.Height = -11
  Font.Name = 'Tahoma'
  Font.Style = []
  OldCreateOrder = False
  OnCreate = FormCreate
  OnDestroy = FormDestroy
  PixelsPerInch = 96
  TextHeight = 13
  object Panel1: TPanel
    Left = 0
    Top = 0
    Width = 635
    Height = 41
    Align = alTop
    TabOrder = 0
    DesignSize = (
      635
      41)
    object Open1: TButton
      Left = 11
      Top = 9
      Width = 75
      Height = 25
      Caption = 'Open'
      TabOrder = 0
      OnClick = Open1Click
    end
    object Rotate1: TButton
      Left = 173
      Top = 9
      Width = 75
      Height = 25
      Caption = 'Rotate'
      TabOrder = 1
      OnClick = Rotate1Click
    end
    object Save1: TButton
      Left = 335
      Top = 9
      Width = 75
      Height = 25
      Caption = 'Save'
      TabOrder = 2
      OnClick = Save1Click
    end
    object AddLayer1: TButton
      Left = 92
      Top = 9
      Width = 75
      Height = 25
      Caption = 'Add Layer'
      TabOrder = 3
      OnClick = AddLayer1Click
    end
    object Exit1: TButton
      Left = 545
      Top = 9
      Width = 75
      Height = 25
      Anchors = [akTop, akRight]
      Caption = 'Exit'
      TabOrder = 4
      OnClick = Exit1Click
    end
    object Merge1: TButton
      Left = 254
      Top = 9
      Width = 75
      Height = 25
      Caption = 'Merge'
      TabOrder = 5
      OnClick = Merge1Click
    end
  end
  object ImageEnView1: TImageEnView
    Left = 0
    Top = 41
    Width = 635
    Height = 258
    Background = clBtnFace
    ParentCtl3D = False
    EnableInteractionHints = True
    Align = alClient
    TabOrder = 1
  end
  object ImageEnProc1: TImageEnProc
    PreviewsParams = [prppShowResetButton, prppHardReset]
    PreviewFont.Charset = DEFAULT_CHARSET
    PreviewFont.Color = clWindowText
    PreviewFont.Height = -11
    PreviewFont.Name = 'Tahoma'
    PreviewFont.Style = []
    Left = 41
    Top = 66
  end
  object ImageEnIO1: TImageEnIO
    PreviewFont.Charset = DEFAULT_CHARSET
    PreviewFont.Color = clWindowText
    PreviewFont.Height = -11
    PreviewFont.Name = 'Tahoma'
    PreviewFont.Style = []
    Left = 76
    Top = 66
  end
  object OpenPictureDialog1: TOpenPictureDialog
    Left = 118
    Top = 66
  end
  object SavePictureDialog1: TSavePictureDialog
    Left = 154
    Top = 69
  end
end

procedure Rotate45Example(aBitMap : TIEBitmap);
var ow, oh : Integer;
begin
  ow := aBitMap.Width;
  oh := aBitMap.Height;
  aBitMap.Rotate(45, True, ierBicubic, clWhite);
  aBitMap.Resize(ow, oh, 0, 0, iehCenter, ievCenter);
  ImageEnView1.Update;
end;
